型号Model | 挤出机型号Extruder Model | 标志线挤出机Marking Line Extruder | 管材规格 Pipe Specification | 生产速度Production Speed | 最高挤出量Maximum Extrusion Capacity |
SC-75 | SCSJ-65×33 | SCSJ-25×25 | F16-F75mm | 0.5-16m/min | 180kg/h |
SC-110 | SCSJ-75×38 | SCSJ-25×25 | F32-F110mm | 0.5-12m/min | 450kg/h |
SC-200 | SCSJ-80×36 | SCSJ-30×25 | F75-F200mm | 0.2-12m/min | 500kg/h |
SC-250 | SCSJ-90×33 | SCSJ-30×25 | F90-F250mm | 0.2-10m/min | 500kg/h |
SC-315 | SCSJ-90×36 | SCSJ-30×25 | F160-F315mm | 0.2-8m/min | 700kg/h |
SC-450 | SCSJ-110×33 | SCSJ-30×25 | F200-F450mm | 0.2-8m/min | 740kg/h |
SC-630 | SCSJ-120×36 | SCSJ-45×30 | F315-F630mm | 0.2-6m/min | 800kg/h |
SC-800 | SCSJ-135×33 | SCSJ-45×30 | F560-F800mm | 0.2-5m/min | 1000kg/h |
SC-1200 | SCSJ-150×36 | SCSJ-45×30 | F630-F1200mm | 0.2-4m/min | 1500kg/h |
